Features:
◆ High ragidity , High reliability, High cuting power
◆ Taiwan 24 position tool storage
◆ 3-linear guideway
◆ Spindle made by Taiwan
Specification
model
|
XH716G |
Model |
Model |
Worktable size ( L×W ) |
1300×600mm |
Max. loading capacity |
600kg |
T - Slots |
5×18×100mm |
X -travel |
1000mm |
Y -travel |
600mm |
Z -travel |
600mm |
Distance from spindle nose to table |
180~780mm |
Spindle inner taper |
ISO40 |
Tool |
BT40 |
Spindle speed range |
20～8000r/min |
Cutting feed ( X 、 Y 、 Z ) |
1~10000mm/min |
Rapid speed ( X 、 Y 、 Z ) |
36000mm/min |
Power of main motor |
7.5kw/11kW |
Max. spindle torque |
35.8N.m |
Positioning accuracy ( X 、 Y 、 Z ) |
±0.01mm |
Repositioning accuracy( X 、 Y 、 Z ) |
±0.005mm |
Storage of tool |
24把 |
Tool change time ( T - T ) |
1.8sec |
| Power supply |
29kVA |
| Overall size ( L×W×H ) |
290×265×245cm |
| Packing Size ( L×W×H ) |
335×300×305cm |
Net weight |
7500kg |
Standard configuration |
·Ball linear guide rail |
|
|
Optional configuration |
·Roller linear guide rail |
|
|
